SAMT SLG1000 DC Solar Sliding Gate Kit
SKU:
SLG1000-SYKCE30
SAMT
$ 1,515.00
Secure Payment
Details
SAMT SLG1000 DC Solar Sliding Gate Kit
Features:
- Die Cast alloy construction
- Soft start and soft stop
- Mechanical and Electronic travel limit switches provide accurate positioning
- Can be mounted on either side of the gate
- Infrared sensors available for additional safety
- Easy to install (full maintenance and installation manual included)
- Solar Power System
- Installable anywhere without the need for connections or excavations
- Also suitable for difficult to access locations with power mains
- Solar energy is free, clean and benefits the environment
- 1 year warranty
Specifications
| Rated voltage | 230V AC 50/60Hz |
| Motor rated voltage | 24Vdc |
| Input power | 110W |
| Ambient temperature range | -20°C /+50°C |
| Max. gate weight | 900kg |
| Max gate width | 6.0m |
| Protection Rating | IP 54 |
| Max. travel limit | 700 mm |
| Moving speed | 15 m/min |
| Motor rotation speed | 3000rpm |
Complete Gate Motor kit includes:
- 1x DC Slider SLG1000 Slide gate motor
- 4x 1.0m Nylon Steel-reinforced gear rack
- 2x Remote Transmitters, 433MHz
- 1x Instruction manual
- 1x Base plate
- 4x Screw(8×40), washer, nut
- 2x Limit switch brackets
- 1x Release key
Solar Kit Specifications
| Specification | Battery Box | Solar Panel |
| Rated Voltage (V) | 24 | 24 |
| Maximum Current (W) | 10 | – |
| Peak Power (Wp) | – | 30 |
| Rated Battery Capacity (Ah) | 20 | |
| Protection Rating | IP 44 | |
| Operating Temperature | -20 ~ +50°C | -40 ~ +85°C |
| Recharging Time | 15 hours* | |
| Dimensions (mm) | 258x235x180h | 390x415x28 |
Complete Solar Kit includes:
- 1x 30W 24V Photovoltaic Solar Panel (Converts solar to electricity)
- 1x Fully Insulated Weatherproof Battery Box
- 1x All wiring included for easy installation
