Ditec OBBI 3BHK Swing Gate Operator Double Leaf
Shop By Categories
Ditec OBBI 3BHK Swing Gate Operator Double Leaf
$ 1,190.00
Out of stock
Secure Payment
Details
PLEASE NOTE: THIS MOTOR HAS BEEN DISCONTINUED
Ditec OBBI 3BHK Swing Gate Operator Single Leaf
Gates for residential application often require an automation able to ensure long lasting, highly reliable gate operation, as well as to perfectly blend in with the look of the gate. Obbi’s smart yet simple design fully meets these requirements and can also be used with any type of modern or period gates. Its very thin frame blends in exceptionally well with the frame of the gate and ensures easy installation thanks to its special connecting system, which may be fixed without welding, if so required, and to its multi-hole rear bracket, easily adjustable to be located in the most suitable operating position by simply changing the through hole combination. In the event of a power failure, the automation can be manually operated by using the key operated release system or automatically operated if a control panel with battery has been installed.
Technical specifications
| Electromechanical actuator | Irreversible for up to 3m wide leaf |
| Maximum capacity | 250 kg x 1.5m
150 kg x 3m |
| Service index | 3 – frequent |
| Intermittent operation | S2 = 30 min
S3 = 50% |
| Power absorption | 24Vdc |
| Input | 3A |
| Thrust | 1500N |
| Opening time | 25s/90° |
| Max travel | 350mm |
| Actuator maximum opening | 110 |
| Release system for manual opening | Key-operated |
| Operating temperature | – 20°C ~ 50°C |
| Protection level | IP54 |
| Product dimensions (mm) | 110 x 200 x 995 |
Kit contains:
– 2 x OBBI 3BH operator
– 1 x Control unit
– 1 x Receiver
– 2 x Ditec GOL4 remotes
